Chrome Moly Forged Fittings
Types:
• Socket Weld (S/W) & SCREWED (SCRD) – Threaded – NPT, BSP, BSPT
Sizes:
• 1/2″ – 4”
Specifications:
• ASTM A182, ASME SA182
Grades:
• GR F 5, F 9, F 11, F 12, F 22, F 91
Dimensions:
• ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Classes:
• 3000LBS, 6000LBS, 9000LBS
Exotic Stainless Forged Fittings
Types:
• Socket Weld (S/W) & SCREWED (SCRD) – Threaded – NPT, BSP, BSPT
Sizes:
• 1/2” – 4”
Specifications:
• ASTM A182, ASME SA182
Grades:
• 304H, 310S/310H, 317L, 321/321H, 347/347H
Dimensions:
• ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Classes:
• 3000LBS, 6000LBS, 9000LBS
Duplex & Super Duplex Forged Fittings
Types:
• Socket Weld (S/W) & SCREWED (SCRD) – Threaded – NPT, BSP, BSPT
Sizes:
• 1/2″- 4”
Specifications:
• ASTM A182, ASME SA182
Grades:
• UNS S31803, S32205, S2205, S32550, S32750, S32760, S32950
Dimensions:
• ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Classes:
• 3000LBS, 6000LBS, 9000LBS
Nickel-Chromium Forged Fittings
Types:
• Socket Weld (S/W) & SCREWED (SCRD) – Threaded – NPT, BSP, BSPT
Sizes:
• 1/8″ – 4″
Specifications/Grades:
• ASTM / ASME 462, 472, 564 – Alloy 20, Nickel 200 / 201, Hastelloy C276, Incoloy 825, Inconel 600, Inconel 625, Monel 400
• ASTM / ASME F51, F53, F60 – Duplex 2205, Super Duplex 2507
Dimensions:
• ANSI / ASME 16.11, BS 3799
Classes:
• 2000LBS, 3000LBS, 6000LBS, 9000LBS
